• Detector type Focal Plane Array (FPA), uncooled micro bolometer


• Detector pixels 320 columns × 240 rows of pixels


• Thermal sensitivity NEΔT 0.08°C at 30°C , f=1.0


• Spectral range 8 to 14 μ m


• Frame frequency 50 Hz


• Focusing Manual


• Field of view/min focus distance 25.6 °× 19.2 ° / 0.4m (lens: 35mm )



• Video output PAL, Composite video

• Display 3.5 ″ color LCD



• Temperature range -20°C to + 250°C


• Accuracy (% of reading) ± 2 ℃ or ± 2%


• Repetition (% of reading) ± 1 ℃ or ± 1%


• Measurement modes Movable spot, Area max, Area min, Area average,
  Self-motion catching max/min


• Menu controls Palettes (Iron, Rainbow, B/W, W/B inv)


• Auto adjust (continuous/manual)


• Set-up functions Data/time, Temperature units °C / ° F , Language, Color code,
  Info field, LCD intensity


• Measurement corrections Variable from 0.1 to 1.0, Reflected ambient

• Type Internal storage (capacity: 200 images)


• Image frame BMP


• Classification Class 2


• Type Semiconductor A1Galnp Diode Laser: 1 mW/635 nm (red)



• Battery Li-lon, Capacity: 2400Ah , 7.2V


• Battery operating time 2 hours, Display show battery status


• Battery charging Standard charger, Input 8.4V DC, Input 100-240 VAC, 50/60Hz
  Voltage 12V DC


• Power saving Automatic shutdown (optional)



• Operating temperature range -15°C to + 45°C (+ 5 ° F to + 113 ° F )


• Storage temperature range -40°C to + 70°C (+ 40 ° F to + 158 ° F )


• Humidity Operating and storage 10% to 95%, non-condensing,


• Encapsulation IP54, IEC 359


• Shock 25G, IEC 68-2-29


• Vibration 2G , IEC 68-2-6



• Weight < 1.4kg including battery


• Size 245mm × 98mm × 273mm

• Digital output Image transfer to PC ( USB2.0)


• Video output Standard RCA composite video
