Wireless
Camera Kit |
|
Product Function
2.4 G locked frequency transmitter
and receiver
Open transmission distance is
100 m in ideal conditions
The receiver also has the infrared
remote control
It can output two lines of audio
and video signals simultaneously
Output can be displayed on TV,
monitor or LCD TV
and so on
The delay time to switch automatically
between the cameras can be set for
20 sec.
General Usage
The product is compact and diaphanous.
It is convenient to take and use anywhere.
It could be used in the supermarket,
marketplace, shops, offices, residence
etc. to monitor the places.
Caution: This product must be
forbidden for the illegal use!
|
Model |
Parameters |
Image Sensor |
1/4" Sharp CCD |
Validity Pixel |
PAL : 512 X 582/NTSC: 512
X 492 |
Horizontal Definition |
380line |
Visual Angle |
60°C |
Minimum illumination |
1Lux/F 1.2 |
Frequency |
C H1: 2.414GHz C H2: 2.432GHz |
C H3: 2.450GHz C H4: 2.468GHz |
Transmission Power |
20mW |
Open Transmission Distance |
100M |
Power |
DC12V/500mA |
Work Temperature |
-10~+50°C |
Size |
46 X 42 X 60mm |
Weight |
115g |
|
|
FEATURES
4 channels video input in
one card, the maximum display/recording
rate is 25 fps under PAL format, and
30 fps under NTSC format
4 screen display modes are
available
Multi alarm triggering method:
sensor, motion, video loss, and HDD
space shortage
Support schedule recording
mode, recycling recording method also
available
MPEG4 video compression format,
5 level recording quality options
available and the recording frame
rate range from 1 to 30 fps adjustable
for each channel
Support multi-channel playback,
searching by time/date and recording
events, images can be zoom/capture/save/print/backup
Support remote surveillance
and PTZ control through web browser,
support dynamic domain name
Remote playback function
Configurable auto reboot function
for preventing PC deadlock
|
* Optional |
