Item |
Value |
| GENERAL |
Transmission Frequency |
ISM 2,400~2,483 MHz |
| Transmission Power |
10mW/CE; 2mW/FCC |
| Operating Frequency |
2414MHz;2432MHz;2450MHz;2468MHz |
| Unobstructed Effective Range |
100m(Min.) |
| Modulation Mode |
FM |
| Operating Temperature |
-10 ~ +50(Degree C) / +14~ +122(Degree F) |
| Storage Temperature |
-20 ~ +60(Degree C) / -4 ~ +140(Degree F) |
| Operating Humidity |
<=85%RH |
| CAMERA |
Imaging Sensor Type |
CMOS |
| Picture Total Pixels |
PAL:628×582 Pixels;
NTSC: 510×492 Pixels
|
| Horizontal Resolution |
380 TV Lines |
| View Angle |
PAL:60°; NTSC:40° |
| Minimum Illumination |
0Lux |
| Night Vision Range |
3m |
| BandWidth |
18M |
| Consumption Current |
110mA (Max.) |
| Power Supply |
DC +8V |
| Dimensions(W×D×H) |
46*42*57 mm |
| Weight |
89g |
| RECEIVER |
Antenna |
50 ohm SMA |
| Receiving Sensitivity |
<=-85dBm |
| Intermediate Frequency |
480MHz |
| Video Output Signal Level |
1.1Vpp±0.2Vpp@75 ohm, S/N >38dM |
| Audio Output Signal Level |
3.0Vpp±1Vpp@600 ohm |
| Consumption Current |
190mA(Max.) |
| Power Supply |
DC +5V |
| Dimensions(W×D×H) |
68*78*16 mm |
| Weight |
119 g |
