Image Sensor : CMOS ,VGA,1/4 inch
Lens : High and clear degree CCD lens
Infrared LED : Support 6 infrared LED, automatic operate in dark environment
Resolution : VGA (640x480)/ CIF(320x240)/ the QCIF(160x120)
Compress format : M-JPEG
Frame rate : 30fps Under the better bandwidth condition
Moving set : Control moving set in the distance , move 120°up and down, 180°left to right
Display : LCD display the IP address /Network mask/gateway IP etc.
Storage mode : Storage picture use CF card socket, support Max.2GB CF card
Input / Output port : Connect 2 switches sensor outside and 1 relay output to alarms
Moving detection : Moving detection and alarms features
Video Transmission : Support 10 customers to visit at the same time
Visit : Build-in Web server, visit the IP camera directly through the web browser.
Certification/ Encryption : Visit the IP camera use password. 3 classes visit authority setting
Network protocol : TCP/ IP, UDP, IMCP, SMTP, HTTP, FTP, DNS, the DDNS DHCP, PPPoE etc
Network connections : Ethernet 10/100Base-T, RJ-45 connector
Software : IP Camera Tool and 16 picture tracking
Software upgrade : Support the FTP software upgrade
Power : 5V / 1A DC
|
